Diagnose faults in circuit boards using a multimeter and oscilloscope in a virtual workshop.
Step into your electronics workshop and learn to solve faults, one measurement at a time.
Circuit Detective combines a diagnostic game with a virtual 3D laboratory. Inspect components, follow circuit traces, place your probes and test your ideas against measurements.
73
MISSIONS TO BUILD YOUR SKILLS
Start with resistors, LEDs and switches. Then explore capacitors, diodes, transistors, rectification and signals. Measure, calculate, choose a component or identify a fault.
HANDS-ON VIRTUAL INSTRUMENTS
Use a multimeter, a two-channel oscilloscope, a function generator and an adjustable power supply. Rotate around circuit boards, zoom in on components and inspect the solder side.
Read the full description
A WORKSHOP FOR EXPERIMENTS
Practice diagnostics and repairs, replace components and build circuits on a virtual breadboard.
UNDERSTAND AS YOU PLAY
Read lessons, component datasheets and hints. Use the built-in calculator to work through your measurements. Your progress is saved on your device.
ONE PURCHASE,
THE COMPLETE GAME
All missions and the workshop are included. No ads, subscription or in-app purchases. Play offline without creating an account. Available in English and French on iPhone and iPad.
Circuits are educational simulations: measurements and components are modeled for learning.
